1. Application Range Tubing:
o Master Tong: 2 3/8" to 3 1/2" (60–89 mm)
o Backup Tong: Up to 4 1/2" (114 mm)
2. High Gear Rated Torque:
1.5 kN·m (1,106 ft-lbs)
3. Low Gear Rated Torque:
6 kN·m (4,425 ft-lbs)
4. High Gear Max Rotation Speed:
85 RPM
5. Low Gear Max Rotation Speed:
20 RPM
6. Opening of Tong Head:
95 mm (3.74")
7. Weight: 220 kg (485 lbs, including backup tong)
8. Rated System Pressure:
1,595 PSI (11 MPa)
9. Max Oil Supply: 100 L/min (26.4 gpm)
1. Application Range Tubing:
o Master Tong: 2 7/8" to 4 1/2"
o Backup Tong: 3 1/2" to 5 1/8"
2. High Gear Rated Torque: 2.5 kN·m (1,844 ft-lbs)
3. Low Gear Rated Torque: 6 kN·m (4,425 ft-lbs)
4. High Gear Max Rotation Speed: 60 RPM
5. Low Gear Max Rotation Speed: 15 RPM
6. Opening of Tong Head: 118 mm (4.65")
7. Weight: 240 kg (529 lbs, including backup tong)
8. Rated System Pressure: 1,450 PSI (10 MPa)
9. Max Oil Supply: 120 L/min (31.7 gpm).
